Optical Data
Dominant wavelength (λd) - blue typical 452 nm*
Dominant wavelength (λd) - green typical 527 nm*
Dominant wavelength (λd) - red typical 625 nm*
LED expected lifetime (L70) 50,000 hours
Lightsource 18 X High Output RGBL LEDs
Notes *: ±1 nm measurement tolerance.
Optional filters Wall Wash Filter, PALCO
Scrim Filter, PALCO
Narrow - 20° Green, PALCO
Medium - 45° Red, PALCO
Wide - 80° Blue, PALCO
10x60° Horizontal - Orange, PALCO
60x10° Vertical - Yellow, PALCO

Photometric
Average CQS (CTC) 89
Average RF / TM-30-15 (CTC) 84
Color temperature range 2000K - 10000K
Efficacy 38.7 lm/W*
Light output - all on 15558
Light output - blue 1604 lm
Light output - green 7903 lm
Light output - red 3276 lm
Lux @ 10m 2533 lux
Lux @ 3m 28145 lux
Lux @ 5m 10132 lux
Max. CRI @ 5600K 81
Max. TLCI @ 5600K 80
Native beam angle(s) 11°
Native field angle(s) 23°

Physical
Color options Black - RAL 9004
IK rating IK06
IP class IP65
Lens material PMMA
Material Plastic
Stainless steel
Tempered Glass
Recycled aluminium
Net dimensions L x H x W (imperial) 14 x 10.6 x 7.2 inches
Net dimensions L x H x W (metric) 356 x 268 x 183 mm
Net weight 7.5 kg (16.5 lbs)

Electrical
Input voltage (nominal) 100 - 240 VAC; 50 / 60 Hz
Max inrush current 230VAC 45 A
Max power consumption 450 W
Max power thru @ 100 V 4.1 A
Max power thru @ 230 V 1.7 A
Power factor 0.978 PF (230 V)
Standby power consumption 10 W

Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Temperature range, operating -20°C to 50°C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -20°C to 50°C
Total heat dissipation, max power 1535.4 BTU per hour
Total heat dissipation, standby 34.1 BTU per hour
Included items
Included items 2 Omega bracket with quater-turn fasteners
