Optical Data
Dominant wavelength (λd) - blue typical 452 nm*
Dominant wavelength (λd) - green typical 527 nm*
Dominant wavelength (λd) - red typical 625 nm*
LED expected lifetime (L70) 50,000 hours
Lightsource 36 X High Output RGBL LEDs
Notes *: ±1 nm measurement tolerance.
Optional filters Wall Wash Filter, PALCO
Scrim Filter, PALCO
Narrow - 20° Green, PALCO
Medium - 45° Red, PALCO
Wide - 80° Blue, PALCO
10x60° Horizontal - Orange, PALCO
60x10° Vertical - Yellow, PALCO

Photometric
Average CQS (CTC) 89
Average RF / TM-30-15 (CTC) 84
Color temperature range 2000K - 10000K
Efficacy 42.7 lm/W*
Light output - all on 33357
Light output - blue 2311 lm
Light output - green 15714 lm
Light output - red 6824 lm
Lux @ 10m 5008 lux
Lux @ 3m 55645 lux
Lux @ 5m 20032 lux
Max. CRI @ 5600K 81
Max. TLCI @ 5600K 80
Native beam angle(s) 11°
Native field angle(s) 24°

Physical
Color options Black - RAL 9004
IK rating IK06
IP class IP65
Lens material PMMA
Material Plastic
Stainless steel
Tempered Glass
Recycled aluminium
Net dimensions L x H x W (imperial) 19.6 x 12.5 x 9.1 inches
Net dimensions L x H x W (metric) 498 x 318 x 232 mm
Net weight 13 kg (28.7 lbs)

Electrical
Input voltage (nominal) 100 - 240 VAC; 50 / 60 Hz
Max inrush current 230VAC 50 A
Max power consumption 850 W
Max power thru @ 100 V 8.4 A
Max power thru @ 230 V 3.6 A
Power factor 0.981 PF (230 V)
Standby power consumption 25 W

Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Temperature range, operating -20°C to 50°C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -20°C to 50°C
Total heat dissipation, max power 2900.2 BTU per hour
Total heat dissipation, standby 85.3 BTU per hour

Included items
Included items 2 Omega bracket with quater-turn fasteners
