Optical Data
LED expected lifetime (L70) 50,000 hours
Lens options (built-in) 10°
Lightsource 48 x high-power 24W RGBW LEDs
Optional filters Elliptical horizontal, I/P, external (10° x 60° angle)
Elliptical vertical, I/P, external (60° x 10° angle)
Wide, P-1/P-6/P-10, external (47° angle)
Medium, P-1/P-6/P-10, external (18° angle)

Photometric
Color temperature range 2000K - 10000K
Efficacy 29 lm/W*
Light output - all LEDs on 40165 lm
Light output - blue 2854 lm
Light output - green 13151 lm
Light output - red 7545 lm
Lumen per kilogram 1922 lm / Kg
Lux @ 10m 6530 lux
Lux @ 3m 72555 lux
Lux @ 5m 26122 lux
Native beam angle(s) 11° (with 10° lens)
18° (with Med filter frame)
47° (with Wide filter frame)
Native field angle(s) 22°

Physical
Color options Black - RAL 9004
Custom color - Any RAL
White - RAL 9010
Effective Projected Area 3.7 Square ft
IK rating IK07
IP class IP65
Lens material PE
Material Aluminium
PC/ASA
Rubber
Steel
Tempered Glass
Net dimensions L x H x W (imperial) 27.7 x 15.8 x 8.1 inches
Net dimensions L x H x W (metric) 702 x 402 x 206 mm
Net weight 20.9 kg (46.1 lbs)

Features
Color calibration SGM proprietary, full color calibration
Dehumidifier Base / Head
Dimming 3 Smooth fade in, DMX-controllable curves: gamma corrected, linear, halogen emulation
Emulation mode / effect Tungsten response emulation
Color Filter Emulation
Filters Magnetic easy-fit spread angle filter frames
LED panel 8 individually controllable segments
Other Studio DMX mode(s)
LED frequency control over DMX
Strobe Ultra-high-speed strobe effects
Intensity, Duration, Rate and FX control channels
Pixel strobe feature (up to 8 segments)
Tilt 0 - 190°
Tilt locking system Locking system with angle indicator

Electrical
Electrical protection Overload protection with automatic recover
Input voltage (nominal) 100 - 277 VAC; 50 / 60 Hz
Max inrush current 230VAC 79 A
Max power consumption 1400 W
Power factor 0.99 PF (230 V)
Power Supply Unit Auto-ranging electronic switch-mode
Standby power consumption 30 W

Programming and Control
16-bit control Dimmer, Red, Green, Blue, White
Cabled DMX 5 pin XLR input/output
DMX channels 4, 6, 8, 9, 10, 21, 27, 30, 32, 35, 52
DMX modes 13
Protocol CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S
USITT DMX512A
RDM ANSI E1.20
Setting and addressing OLED graphical display / 4 buttons
RDM ANSI E1.20
Standalone mode Quick Color
3 programs with up to 24 scenes
Wireless DMX Lumen Radio with RDM

Connections
DMX data in/out IP65 XLR 5-pin connector, Female
IP65 XLR 5-pin connector, Male
Power Power input connector & link-thru

Installation
Mounting point 3 x two quarter-turn locking points for two or three Omega Brackets
Orientation Any
Rigging possibilities Hanging (Omega Bracket included) or ceiling/wall mount (optional)
Safety features 2 attachment points for safety wire
Minimum distance to combustible materials: 0.3 meter (11 in).

Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Temperature range, operating -40°C to 50°C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -40°C to 80°C
Thermal protection Automatic overtemperature protection
Total heat dissipation, max power 4776.8 BTU per hour
Total heat dissipation, standby 102.4 BTU per hour

Included items
Included items 2 Omega bracket with quater-turn fasteners
2 m IP66 power cable pigtail
Safety instructions and installation quick guide

Conforms To
CE - 2014/30/EU: EMC Directive EN 55015
EN 61547
EN 61000-3-2
EN 61000-3-3
EN 55032
EN 55035
CE - 2014/35/EU: Low Voltage Directive EN 60598-1
EN 60598-2-17
EN 62471
EN 60529
RoHS2 Directive 2011/65/EU
UL UL Std. 1573

Certified To
CSA CSA-E598-2-17-98, Ed: 1
CSA E60598-1, Ed: 3
