Optical Data
LED expected lifetime (L70) 50,000 hours
Lens options (built-in) 110°
Lightsource 2,048 x RGB SMD LEDs & 2,048 x white SMD LEDs (5,700K)
Optional filters Extra medium angle soft diffusion, Q, external
Extra wide angle soft diffusion, Q, external
Elliptical horizontal effect, Q, external
Elliptical vertical effect, Q, external

Photometric
Average CRI (CTC) 83
Color temperature range 2000K - 10000K
Efficacy 47.6 lm/W*
Light output - all LEDs on 57140 lm
Light output - blue 3032 lm
Light output - green 15625 lm
Light output - red 5609 lm
Lumen per kilogram 2886 lm / Kg
Lux @ 10m 223 lux
Lux @ 3m 2593 lux
Lux @ 5m 893 lux
Native beam angle(s) 104° (with 110° lens)
Native field angle(s) 146°

Physical
Color options Black - RAL 9004
Custom color - Any RAL
White - RAL 9010
Effective Projected Area 3.7 Square ft
IP class IP65
Material Aluminium
PC/ASA
Plastic
Rubber
Steel
Tempered Glass
Net dimensions L x H x W (imperial) 27.7 x 15.8 x 8.1 inches
Net dimensions L x H x W (metric) 702 x 402 x 206 mm
Net weight 19.8 kg (43.7 lbs)

Features
Color calibration SGM proprietary, full color calibration
Dehumidifier Base / Head
Dimming 3 Smooth fade in, DMX-controllable curves: gamma corrected, linear, halogen emulation
Emulation mode / effect Tungsten response emulation
Color Filter Emulation
Filters Magnetic easy-fit spread angle filter frames
LED panel 8 individually controllable segments
Other Studio DMX mode(s)
LED frequency control over DMX
Strobe Ultra-high-speed strobe effects
Intensity, Duration, Rate and FX control channels
Pixel strobe feature (up to 8 segments)
Tilt 0 - 190°
Tilt locking system Locking system with angle indicator

Electrical
Electrical protection Overload protection with automatic recover
Input voltage (nominal) 100 - 277 VAC; 50 / 60 Hz
Max inrush current 230VAC 110 A
Max power consumption 1250 W
Power factor 0.99 PF (230 V)
Power Supply Unit Auto-ranging electronic switch-mode
Standby power consumption 39 W

Programming and Control
16-bit control Dimmer, Red, Green, Blue, White
Cabled DMX 5 pin XLR input/output
DMX channels 6, 8, 10, 27 or 30
DMX modes 7
Protocol CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S
USITT DMX512A
RDM ANSI E1.20
Setting and addressing OLED graphical display / 4 buttons
RDM ANSI E1.20
Standalone mode
Standalone mode Quick Color
Up to 24 programmable scenes
Wireless DMX Lumen Radio with RDM

Connections
DMX data in/out IP65 XLR 5-pin connector, Female
IP65 XLR 5-pin connector, Male
Power Power input connector & link-thru

Installation
Mounting point 3 x two quarter-turn locking points for two or three Omega Brackets
Orientation Any
Rigging possibilities Hanging (Omega Brackets included)
Safety features 2 attachment points for safety wire
Minimum distance to combustible materials: 0.3 meter (11 in).

Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Temperature range, operating -40°C to 50°C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -40°C to 80°C
Thermal protection Automatic overtemperature protection
Total heat dissipation, max power 4265 BTU per hour
Total heat dissipation, standby 133.1 BTU per hour

Included items
Included items 2 Omega bracket with quater-turn fasteners
2 m IP66 power cable pigtail
Safety instructions and installation quick guide

Conforms To
CE - 2014/30/EU: EMC Directive EN 55015
EN 61547
EN 61000-3-2
EN 61000-3-3
EN 55032
EN 55035
CE - 2014/35/EU: Low Voltage Directive EN 60598-1
EN 60598-2-17
EN 62471
EN 60529
RoHS2 Directive 2011/65/EU
UL UL Std. 1573

Certified To
CSA CSA-E598-2-17-98, Ed: 1
CSA E60598-1, Ed: 3
