SOURCE

LED Engine (Center): Dual White LED COB

LED Engine (Eye Candy): 120 x Custom RGB LEDs

Max Integrating Sphere Lumens: 52,000

LPW: 52

LED Life: 50,000 hours

COLOR

Color Mixing: RGB color mixing in eight (8) segments across fixture face

Color Temperature: Variable from 3200 K to 7500 K via CT channel

OPTICAL

Light Dispersion (with Reflector Dome): 60° central blinder/strobe Wide area and haze color light distribution Light Dispersion (with EC Dome) 120° degree color and white distribution

Aperture Size: 216 mm Flicker Control/Hz Range 2.4 kHz and 16.6 kHz

CONTROL

Input Method: DMX (5-pin)

Protocols: DMX via RS-485

Modes (Channel Footprint): Reduced (7), Standard (19), or Expanded (40)

RDM Functions: Yes

Strobe Functions: Yes

Macro Functions: Yes

Pixel Control: Eight (8) pixel segment control

UI Type: Black and white display with / 4-button navigational control / NFC configuration

Local Control: Yes

Dimming Performance: 16-bit, DMX controlled

ELECTRICAL

Voltage Range: 100–240 V 50–60 Hz

Input Method: Seetronic® X Series IP65 input or powerCON / TRUE1 TOP

Wattage: 1000 W

Current (Max): 9.54 A @ 100 V / 3.62 A @ 240 V

Inrush (First Half Cycle) : 120 V: 25 A /  230 V: 101 A

Fixtures per Circuit: 1 fixture (R20 module or similar) / Note: X Series IP65 connector rated for / 20 A (120 V/60 Hz) and / 16 A (240 V/50 Hz)

THERMAL

Ambient Operating Temp: -10°C to 40°C (14°F to 104°F)

Continuous Operation: Yes

Fan Mode: Four fan modes: Boost, Standard, Studio, Quiet

PHYSICAL

Materials: Aluminum with acrylic dome

Color Options: Black

Mounting Options: Any orientation

IP Rating: IP65

Weight (with Reflector Dome): 7.0 kg (15.5 lb)

Included Accessories: Reflector Dome / EC Dome / X Series IP65 to bare end fixture tail / Yoke / Safety cable

WARRANTY

Fixture Warranty: Five (5) years for light engine / Two (2) years for complete fixture

Warranty Details: etcconnect.com/Support/Warranty.aspx

REGULATORY & COMPLIANCE

Approved Regulatory Standards: cETLus Listed / Listed to UL 1573 / Certified to CSA STD. C22.2 No: 166 / CE Compliant UKCA Compliant

Complies to the ROHS Directive: Yes

SAFETY

Safety: Minimum distance to illuminated /surface = 1.0 m (3.4 ft) Minimum distance from fixture head to combustible materials = 0.1 m (4.0 in)

NOTES: All LED sources experience some lessening of light output and some color shift over time. LED output will vary with thermal conditions. Thermal conditions can be affected by ambient temperatures and orientation.
