GENIO BlinderDot
- Genio Series
.png)
GENIO BlinderDot turns the audience into part of the show. It works as a blinder, a pixel dot, a par can or even a pendant, and can be preconfigured in 4-Lite, 8-Lite or larger builds, so you start with the exact configuration your design calls for.
A 400W RGBALW source pushes up to 17,000 lumens through a 50° beam angle, with CRI up to 96 for colour that holds up on camera as well as in the room.
Hit the whole crowd in one blast, or dial it back for something subtler - the control is the point, not just the output.
Optical Data
Lightsource: RGBALW
Photometric
Color quality - CRI: >90
Color temperature range: 2000K - 10000K
Light output - all on 17000 lm*
Native beam angle(s) 50°
Native field angle(s) 90°
Physical
Color options: Black - RAL 9004
IP class: IP65
Material: Aluminium; Plastic; Stainless steel ;Tempered Glass
Net dimensions L x H x W (imperial): 6.3 x 8.4 x 6.3 inches
Net dimensions L x H x W (metric): 160 x 213 x 160 mm
Net weight 3.5 kg (7.7 lbs)
Electrical
Input voltage (nominal): 100 - 240 VAC; 50 / 60 Hz
Max power consumption: 400 W
Programming and Control
Protocol: sACN Art-Net
Setting and addressing: NFC RDM
Connections
Ethernet Connections: RJ45 connectors
Installation
Maximum Units Vertical: 17 pcs
Mounting point: 2 M-8 threaded mounting points (suitable for the optional rear-bracket)
Rigging possibilities: Hanging (Using the GENIO compatible connectors)
Safety features: Mount for safety wire
Thermal
Cooling: Active, Forced Air, Temperatureregulated
Humidity (max.): 98 %
Temperature range, operating: -20°C to 45°C
Temperature range, start-up: -20°C to 45°C
Temperature range, storage: -20°C to 45°C
Thermal protection: Automatic overtemperature protection
Total heat dissipation, max power: 1364.8 BTU per hour
Included items
Included items: 2 x GENIO Rigging Connector; 1 x GENIO Fixture Connector, M Foam Insert
