GENIO PixelBar
- Genio Series
GENIO PixelBar is where the system gets its pulse. 40 individually controllable RGB sections and 20 white zones run independently or together, backed by a 600W source pushing 31,000 lumens - enough for a genuine white strobe, not just a bright wash.
Built-in electronic frost softens the output on demand, so the same bar can snap sharp for a strobe hit or melt into a smooth wash a beat later.
Optical Data
Frost: Electronic Frost
Lightsource: 40 x RGB Controllable Segments + 20 x CW Strobe Segments
Photometric
Color quality - CRI >90
Color temperature range: 2000K - 10000K
Light output - all on: 31000 lm*
Physical
Color options: Black - RAL 9004
IP class: IP65
Material: Aluminium, Plastic, Stainless steel, Tempered Glass
Net dimensions L x H x W (imperial): 39.4 x 3.5 x 5.1 inches
Net dimensions L x H x W (metric): 1000 x 90 x 129 mm
Net weight 8.5 kg (18.7 lbs)
Electrical
Input voltage (nominal) 100 - 240 VAC; 50 / 60 Hz
Max power consumption: 600 W
Programming and Control
Protocol: sACN Art-Net
Setting and addressing: NFC RDM
Connections
Ethernet Connections: RJ45 connectors
Installation
Maximum Units Vertical: 6 pcs
Mounting point: 2 x 2 quarter-turn locking points for one or two Omega brackets
Rigging possibilities: Hanging (Using the GENIO compatible connectors)
Safety features: Mount for safety wire
Thermal
Cooling: Active, Forced Air, Temperatureregulated
Humidity (max.): 98 %
Temperature range, operating: -10°C to 50°C
Temperature range, start-up -10°C to 50°C
Temperature range, storage -10°C to 50°C
Thermal protection: Automatic overtemperature protection
Total heat dissipation, max power: 2047.2 BTU per hour
Included items
Included items: 2 x GENIO Fixture Connector, M; 4 x GENIO Rigging Connector Foam Insert
