Optical Data

Light Source: 6 x10W RGBL LEDs

Beam Angle: 12° (standard lens)

LED expected lifetime:50000H

Magnetic frost filter: 20º, 30º, 45º

Color Temperature range:3000K / 3500K / 4000K / 4500K / 5000K / 6000K / 7000K / 8000K / 9000K / 10000K

LED PWM Frequency: 600 Hz / 1200 Hz / 2400 Hz / 4800 Hz / 12 kHz / 18 kHz

Battery working time @ full light: 3–4 h

Battery working time @ auto: 8 h

Battery charging time:  4–5 h

Photometric

Light output: 1358 lm

Lux: 2 m: 4712 lx  / 5 m: 754 lx  / 8 m: 295 lx

10 m: 189 lx

Features

Dimming: 0–100%

Dimming curve: Linear / Square Law / Inverse Square Law / S-Curve

Dimmer: 0-255

Filters: Magnetic filters (optional)

LED panel: 6 x 10W RGBL

Strobe: 0–20 Hz adjustable

Tilt: 0–90°

Indicator: LCD display

Electrical Data

Power: 53 W

Standby power consumption:

Input voltage: DC 15V/5A

Electrical protection: SHORT / O.C.P / O.V.P

Operator and Control

DMX modes: 6

DMX channels:  HSV / 2 / 5 / 8 / 11 / 15 ch

Protocol: USITT DMX512A, RDM ANSI E1.20, Wireless DMX

Setting and addressing:

Manual via display buttons

RDM

Connections

Power Connection: H07RN-F cable

Cable Length (power): 1.5 m x 2.5 mm²

Physical

Color options: Fine sand black (RAL 9004)

IK class: IK07

IP class: IP65

Temperature range, operating:

Lens material: PMMA

Body Material: Aluminium

Dimensions: 225 x 150 x 130.5 mm

Weight: 3 kg
